1-4 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
1.2 Replaceble Components Overview
This section contains illustrations that you can use to become familiar with the
components of the Sun Fire X4100/X4100 M2 servers.
1.2.1 Sun Fire X4100/X4100 M2 Server Front Panel
FIGURE 1-1 shows the features of the front panel.
FIGURE 1-1 Sun Fire X4100/X4100 M2 Server Front Panel
1.2.2 Sun Fire X4100/X4100 M2 Server Back Panel
FIGURE 1-2 shows the features of the back panel.
Figure Legend
1 Power/OK LED
2 Power button
3 DVD-ROM drive
4 USB port
5 Serial number sticker on bezel
6 Hard disk drives (2)
21
4 6
3
5
