3-1
CHAPTER
3
Maintaining the Sun Fire Servers
This chapter contains information and procedures for servicing the Sun Fire server
hardware, including component removal and replacement procedures. The sections
include:
■ Section 3.1, “Tools and Supplies Needed” on page 3-2
■ Section 3.2, “Locations of Replaceable Components” on page 3-2
■ Section 3.3, “Servicetool FRU Update Procedure” on page 3-2
■ Section 3.4, “Powering Off the Server” on page 3-4
■ Section 3.5, “Removing the Main Cover of the Sun Fire X4100/X4100 M2 Server”
on page 3-6
■ Section 3.6, “Removing the Front Bezel of the Sun Fire X4100/X4100 M2 Server”
on page 3-7
■ Section 3.7, “Removing the Front Cover of the Sun Fire X4100/X4100 M2 Server”
on page 3-8
■ Section 3.8, “Removing the Main Cover of the Sun Fire X4200/X4200 M2 Servers”
on page 3-10
■ Section 3.9, “Removing the Front Bezel of the Sun Fire X4200/X4200 M2 Servers”
on page 3-11
■ Section 3.10, “Removing the Front Cover of the Sun Fire X4200/X4200 M2 Servers”
on page 3-12
■ Section 3.11, “HT Jumper Configuration for Single-CPU Servers (Sun Fire X4100
M2 and X4200 M2)” on page 3-13
■ Section 3.12, “Replaceable Component Procedures” on page 3-14
Note – All information in this chapter applies to Sun Fire X4100/X4200 and
X4100 M2/X4200 M2 servers, unless otherwise noted in the text.
