B-2 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
Note – This memory test is performed only if Quick Boot is not enabled from the
Boot Settings Configuration screen. Enabling Quick Boot causes the BIOS to skip the
memory test. See Section B.3, “Changing POST Options” on page B-3 for more
information.
3. The BIOS polls the memory controllers for both correctable and uncorrectable
memory errors and logs those errors into the service processor.
B.2 Redirecting Console Output
Use this procedure to access the service processor and redirect the console output so
that the BIOS POST codes can be read.
1. Initialize the BIOS Setup utility by pressing the F2 key while the system is
performing the power-on self-test (POST).
2. The BIOS Main Menu screen is displayed. Select Advanced.
3. The Advanced Settings screen is displayed. Select IPMI 2.0 Configuration.
4. The IPMI 2.0 Configuration screen is displayed. Select the LAN Configuration
menu item.
5. Select the IP Address menu item.
The service processor’s IP address is displayed using the following format:
Current IP address in BMC: xxx.xxx.xxx.xxx
6. Start a web browser and type the service processor’s IP address in the browser’s
URL field.
7. When you are prompted, type a user name and password as follows:
User name: root
Password: changeme
8. When the ILOM Service Processor GUI screen is displayed, click the Remote
Control tab.
9. Click the Redirection tab.
10. Set the color depth for the redirection console at either 6 or 8 bits.
11. Click the Start Redirection button.
The javaRConsole window is displayed and prompts you for your user name and
password again.
