3-34 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
Supported components and their part numbers are subject to change over time. For
the most up-to-date list of replaceable components for these servers, refer to:
http://sunsolve.sun.com/handbook_pub/Systems/
1. Click the name and model of your server.
2. On the product page that opens for the server, click Full Components List to
view a list of components.
Use the following procedure to install a DVD-ROM upgrade kit.
1. Power off the server as described in
Section 3.4 on page 3-4.
2. If the server is in a rack, slide it far enough from the rack so that you can
remove the main cover and front cover. If you cannot safely view and access the
component, remove the server from the rack.
3. Remove the main cover as described in
Section 3.5 on page 3-6 or Section 3.8 on
page 3-10.
4. Remove the front bezel as described in
Section 3.6 on page 3-7 or Section 3.9 on
page 3-11.
Note – Always unfasten the bezel’s securing screw before removing the bezel.
5. Remove the front cover as described in
Section 3.7 on page 3-8 or Section 3.10 on
page 3-12.
6. Install the DVD-slot faceplate to the front bezel. See
FIGURE 3-26.
a. Lay the bezel face down on a work surface.
b. Use a No. 2 Phillips screwdriver to remove the two screws that secure the
blank filler panel to the bezel. Save the screws in a safe place because you
will reinstall them in a following step.
c. Remove the blank filler panel and set it aside.
d. Set the new DVD-slot faceplate in place in the bezel opening.
Ensure that the ejector button on the faceplate is oriented toward the bottom of
the bezel.
e. Using an adjustable torque driver, reinstall the two screws that secure the
faceplate to the bezel. Tighten screws to 7 in-lbs (0.8 Nm).
