1-2 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
TABLE 1-1 summarizes and compares the features of the servers.
TABLE 1-1 Server Features
Feature or
Component Sun Fire X4100/X4100 M2 Servers Sun Fire X4200/X4200 M2 Servers
CPU
Sun Fire X4100:
Up to two AMD64 Opteron 200 Series
single- or dual-core processors (1-MB L2
cache per core)
Sun Fire X4100 M2:
Up to two AMD64 Opteron 2200 Series
single- or dual-core processors (1-MB L2
cache per core)
Sun Fire X4200:
Up to two AMD64 Opteron 200 Series
single- or dual-core processors (1-MB L2
cache per core)
Sun Fire X4200 M2:
Up to two AMD64 Opteron 2200 Series
single- or dual-core processors (1-MB L2
cache per core)
Memory
Sun Fire X4100:
Up to eight DIMMs (up to 32GB capacity)
Qualified DIMMs:
• 400-MHz Registered ECC DDR1 DIMMs
Sun Fire X4100 M2:
Up to eight DIMMs (up to 32GB capacity)
Qualified DIMMs:
• 667-MHz Registered ECC DDR2 DIMMs
Sun Fire X4200:
Up to eight DIMMs (up to 32GB capacity)
Qualified DIMMs:
• 400-MHz Registered ECC DDR1 DIMMs
Sun Fire X4200 M2:
Up to eight DIMMs (up to 32GB capacity)
Qualified DIMMs:
• 667-MHz Registered ECC DDR2 DIMMs
Disk drives Two Serial Attached SCSI (SAS) disk drives
(2.5 inch or 63.5 mm); up to four disk drives
as a factory-configured option
Four Serial Attached SCSI (SAS) drives
(2.5 inch or 63.5 mm)
Board
management
controller (BMC)
Motorola MPC8248 @ 266MHz Motorola MPC8248 @ 266MHz
RAID options Four-channel SAS RAID disk controller Four-channel SAS RAID disk controller
Network I/O • Four 10/100/1000 BASE-T Gigabit
Ethernet ports (RJ-45 connectors)
• One 10/100 BASE-T Ethernet
management port (RJ-45 Connector)
• One RS-232 serial port (RJ-45 Connector)
• Four 10/100/1000 BASE-T Gigabit
Ethernet ports (RJ-45 connectors)
• One 10/100 BASE-T Ethernet
management port (RJ-45 Connector)
• One RS-232 serial port (RJ-45 Connector)
PCI I/O
Sun Fire X4100:
• One 133-MHz, low-profile PCIX slot
• One 100-MHz, low-profile PCIX slot
• Right-angle PCI risers
Sun Fire X4100 M2:
• Two 8-lane, low-profile PCIE slots
• Right angle PCIE risers are provided
Sun Fire X4200:
• One 133-MHz PCIX slot
• One 100-MHz PCIX slot
• Three 66-MHz PCIX slots
Sun Fire X4200 M2:
• Four 8-lane PCIE slots
• One 133-MHz PCIX slot
