3-78 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
1. Power off the server as described in Section 3.4 on page 3-4.
2. If the server is in a rack, remove the server from the rack.
3. Remove the main cover as described in
Section 3.5 on page 3-6 or Section 3.8 on
page 3-10.
4. Remove the front bezel as described in
Section 3.6 on page 3-7 or Section 3.9 on
page 3-11.
Note – Always unfasten the bezel’s securing screw before removing the bezel.
5. Remove the front cover as described in
Section 3.7 on page 3-8 or Section 3.10 on
page 3-12.
6. Remove all PCI cards.
a. Disconnect any external cables from the PCI cards.
b. Working from the rear of the chassis, pivot each card latch to release the PCI
cards. See
FIGURE 3-58 and FIGURE 3-59 on page 76.
c. Pull the PCI cards out of the PCI slots. Ensure that each PCI card's rear
connector panel is released from the tabs on the chassis rear panel.
7. Sun Fire X4200/X4200 M2 Only: Pivot the PCI card latches back to their closed
positions.
8. Remove the Graphics Redirect and Service Processor (GRASP) board, as
described in
Section 3.12.10 on page 3-51.
9. Remove all DIMMs from the motherboard. For details, see “Replacing DIMMs”
on page 3-65.
10. Remove all CPUs from the motherboard.
Refer to one of the following procedures, depending on your model of the server:
■ “Replacing a CPU and Heatsink (Sun Fire X4100 and X4200 Servers)” on
page 3-17
■ “Replacing a CPU and Heatsink (Sun Fire X4100 M2/X4200 M2 Servers)” on
page 3-23
11. Disconnect and remove the interconnect cable that connects the motherboard
and the front I/O board. See
FIGURE 3-62 and FIGURE 3-63.
