Appendix D Sensors D-3
ps0.pwrok SP/SP-Board
ps1.prsnt U46, on MB
ps1.vinok U46, on MB
ps1.pwrok SP/SP-Board
io.id1.prsnt U46, on MB
mb.t_amb U46, on MB
mb.v_bat U46, on MB
mb.v_+3v3stby U46, on MB
mb.v_+3v3 U46, on MB
mb.v_+5v U46, on MB
mb.v_+12v U46, on MB
mb.v_-12v U46, on MB
mb.v_+2v5core U46, on MB
mb.v_+1v5core U46, on MB
mb.v_+1v2core U46, on MB
fp.t_amb U63, on MB
pdb.t_amb U1, on 502-6902
io.t_amb U6, on 502-6978
p0.t_core U46, on MB
p0.v_vdd U46, on MB
p0.v_vddio U46, on MB
p0.v_vtt U46, on MB
p1.t_core U46, on MB
p1.v_vdd U46, on MB
p1.v_vddio U46, on MB
p1.v_vtt U46, on MB
ft0.fm0.f0.speed U6, on 502-6978
ft0.fm1.f0.speed U6, on 502-6978
ft0.fm2.f0.speed U6, on 502-6978
ft1.fm0.f0.speed U6, on 502-6978
TABLE D-1
Sensor Name Location
