Chapter 1 Introduction 1-7
FIGURE 1-4 Sun Fire X4100 M2 Replaceable Component Locations
12 Battery
13 DIMMs (up to 4 for each CPU)
14 CPUs and heatsinks (2)
15 Front I/O board
16 Front panel indicator board
Figure Legend
1 Power supplies (2)
2 Power distribution board
3 Flex cable (underneath cable retainer)
4 Hard disk drive backplane
5 DVD-ROM drive
6 Hard drives (2), 4-drives option available with no DVD-ROM
7 Fan modules (6)
8 Fan connector boards (2) (not visible—underneath fan modules)
Figure Legend
1
5
12
6
14
8
7
15
16
10
4
13
11
9
23
