F-20 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
F.3.10 PHY Properties Screen
The PHY Properties screen (shown below) allows you to view and modify PHY-
specific settings.
TABLE F-9 describes the fields of the screen.
Note – The Link Error Settings values on this screen only display the current values
for this PHY and cannot be modified. To modify the Threshold values, return to the
Advanced Adapter Properties screen.
********************************************************************************
* LSI Logic MPT Setup Utility v6.02.00.00 (2005.07.08) *
* PHY Properties -- SAS1064 *
* *
* PHY 2 (3rd of 4 PHYs) *
* SAS Port 2 *
* Link Status Enabled, 3.0 Gbps *
* Discovery Status 00000000 *
* *
* Device Identifier FUJITSU MAV2073RCSUN72G 0301 *
* Scan Order 2 *
* Device Information SAS *
* SAS Address 500000E0:10D26642 *
* *
* Link Error Link Error Threshold Threshold *
* Settings Count Count Time(Secs) *
* Invalid DWORDs 0 0 0 *
* Loss of DWORD Sync 0 0 0 *
* Running Disparity Errors 0 0 0 *
* PHY Reset Errors 0 0 0 *
* Reset Link Error Counts *
* *
* Esc = Exit Menu F1/Shift+1 = Help *
* Enter = Reset Phy error logs Alt+N = Next Phy Alt+P = Previous Phy *
********************************************************************************
