Appendix F Serial Attached SCSI BIOS Configuration Utility F-27
********************************************************************************
* LSI Logic MPT Setup Utility v6.02.00.00 (2005.07.08) *
* View Array -- SAS1064 *
* Array 1 of 1 *
* Identifier LSILOGICLogical Volume 3000 *
* Type IM *
* Scan Order 2 *
* Size(MB) 69618 *
* Status Optimal *
* *
* Manage Array *
* *
* Scan Device Identifier RAID Hot Drive Pred Size *
* ID Disk Spr Status Fail (MB) *
* 3 FUJITSU MAV2073RCSUN72G 0301 Yes No Secondary No 69618 *
* 4 FUJITSU MAV2073RCSUN72G 0301 Yes No Primary No 69618 *
* *
* *
* *
* *
* *
* *
* Esc = Exit Menu F1/Shift+1 = Help *
* Enter=Select Item Alt+N=Next Array C=Create an array *
********************************************************************************
TABLE F-11 View Array Screen Field Descriptions
Field Description
Array The number of the array.
Identifier The identifier of the array.
Type The RAID type of the array.
Scan Order The scan order of the array.
Size(MB) The size of the array.
Status The status of the array.
Scan ID The order in which devices are scanned.
Device Identifier The ASCII device identifier string extracted from the device’s inquiry
data.
