Appendix F Serial Attached SCSI BIOS Configuration Utility F-37
6. (Optional) Add a hotspare to the volume by moving the cursor to the Hot Spare
column and pressing the + key, - key, or space bar.
7. When the volume has been fully configured, press C and select Save changes,
then exit this menu to commit the changes.
The Configuration Utility will pause while the array is being created.
Note – RAID 1 provides protection against the failure of a single disk. When a disk
fails, it is rebuilt to a hotspare if one is available. This can greatly increase the level of
protection that RAID 1 provides.
Note – Even though multiple volumes can be created, the hotspare is a global
hotspare. Only one active hotspare is allowed for all volumes.
F.4.4 Managing Hot Spares
Follow these steps to add a hotspare to a RAID 1 volume.
1. Select Manage Hot Spare.
2. Select a disk from the list by pressing the + key, - key, or space bar.
Note – A hotspare must be valid RAID disk, as defined in Section F.4.3, “Creating a
RAID 1 Volume” on page F-36.
3. After you select the hotspare disk, press C.
4. Select Save changes then exit this menu to commit the changes.
The Configuration Utility will pause while the hotspare is being added.
Follow these steps to delete a hotspare from a RAID 1 volume.
1. Select Manage Hot Spare.
2. Remove the current hotspare disk from the list by pressing the + key, - key, or
space bar.
3. After you clear the hotspare, press C.
4. Select Save changes then exit this menu to commit the changes.
The Configuration Utility will pause while the hotspare is being removed.
