2-54 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
7. Reconnect power cords to the server.
The server powers up to standby power mode, indicated when the Power/OK
LED on the front panel is flashing.
8. Return the server to main power mode by using a nonconducting pointer or
stylus to press and release the recessed Power button on the front panel.
Note – You must allow the entire server, not just the SP, to reboot to main power
mode to complete the password reset. This is because the state of this jumper cannot
be determined without the host CPU running. Wait until the end of POST, when you
see the CMOS password cleared by jumper message, after which both the
BIOS and SP passwords are reset.
■ The ILOM SP password is reset to the default, changeme.
■ The BIOS password is also reset by a separate operation performed by the BIOS
when it discovers the presence of this jumper. The BIOS password is not reset to
changeme, it is removed so that there is no longer a BIOS password set. If you
had a BIOS password set, you are no longer prompted for one.
9. Log in to the ILOM web GUI using root as the username and changeme as the
password. Refer to the Integrated Lights Out Manager Administration Guide,
819-1160.
10. Change the default password to a password of your choice.
11. Repeat steps 1 through 8 to remove the P4 or J12 jumper. (Remove the jumper in
Step 5 rather than inserting it.)
Note – If you do not remove this jumper, the ILOM SP and BIOS passwords will be
reset every time you power-cycle the server.
