1-6 GENERAL INFORMATION
PROPELLERS
An outboard motor is designed to develop its rated power within
a specified engine speed range. The maximum rated power
delivered by the DF25 / 30 models are shown below.
Blade × Diam. (in.) × Pitch (in.)
3
× 10 - ¼ × 9 (P901)
3
× 10 - ¼ × 10 (P1001)
3
× 10 - ¼ × 11 (P1101)
3
× 10 - ¼ × 12 (P1201)
3
× 10 - ¼ × 13 (P1301, PS1301)
3
× 10 - ¼ × 14 (P1401)
3
× 10 - ¼ × 15 (P1501)
If the standard propeller fails to meet the above requirement,
use another pitch propeller to hold the engine speed within
the range specified above.
Propeller selection chart
Recommended full
throttle speed range
DF25 5000 – 5600 r/min
DF30 5500 – 6100 r/min
Installing a propeller with pitch either too high or too
low will cause incorrect maximum engine speed, which
may result in severe damage to the motor.
