5-8 FUEL SYSTEM
CLEANING & INSPECTION
Clean thoroughly with cleaning solvent and compressed air
before inspection.
"
Wear safety glasses when using compressed air to
expel solvent, carburetor cleaner etc.
Do not place any rubber, plastic and non-metallic parts
in cleaning solvent, as severe damage or deteriora-
tion will result.
NOTE :
Wire or small drill bits must not be used to clean carburetor
orifices and jet.
CARBURETOR BODY
Inspect the carburetor body. If cracks or other damage are found
on any component, replace it.
Clean carburetor body so that there is no obstruction.
PILOT SCREW (for applicable carburetor only)
Check pilot screws for wear, damaged threads, broken tips and
replace if necessary.
JET, NOZZLE
Inspect the jet and nozzle. If cracks or other damage are found
on the jet and nozzle, replace them.
Clean the jet and nozzle thoroughly so that there is no ob-
struction.
