Suzuki DF 30 - Inspection; Propeller; Gearcase

10-8 LOWER UNIT
INSPECTION
NOTE:
If any component is worn excessively, cracked, defective or
damaged in any way, it must be replaced.
NOTE:
Thoroughly wash all metal components with cleaning solvent
and dry with compressed air.
"
Wear safety grasses when using compressed air.
PROPELLER
• Inspect the propeller for bent, chipped or broken blades.
Replace or repair propeller if in damaged condition.
• Inspect propeller bush splines. Replace or repair propeller if
splines are worn or damaged.
• Inspect propeller bush for deterioration or slipping.
Replace if necessary.
GEARCASE
• Inspect the gearcase. Replace if cracked or damaged.
• Visually check the pinion bearing. Replace if pitted, noisy or
rough.
NOTE:
If removal and replacement are required, see the “PINION
BEARING” section on page 10-6.
1 Forward gear
bearing
2 Pinion bearing
