ELECTRICAL 4-11
NEUTRAL SWITCH
Check for continuity / infinity of the neutral switch.
09930-99320 : Digital tester
Tester range : (Continuity)
1. Disconnect neutral switch lead wires.
2. Check continuity / infinity between Yellow / Green and Brown
lead wires while operating shift lever or remo-con handle.
If out of specification:
• 1st Check switch position adjustment, readjust if necessary.
• 2nd Replace neutral switch.
NOTE:
After installing neutral switch, check for proper correct function
by operating remo-con handle or shift lever.
Shift position Tester indicates
Neutral Continuity
Forward Infinity
Reverse Infinity
[
S
FORWARD
NEUTRAL
REVERSE
Y/G
Br
