CHASSIS 7-13
WHEEL BEARING
• Apply SUZUKI SUPER GREASE to the wheel bearings.
' 99000-25030: SUZUKI SUPER GREASE “A” (USA)
99000-25010: SUZUKI SUPER GREASE “A” (Others)
• First install the left wheel bearing, then install the right wheel
bearing and spacer with the special tools and used bearing.
$ 09941-34513: Bearing/Steering race installer set
09913-70210: Bearing installer set (& 40)
#
1 Spacer
2 Old bearing
A Left
B Right
C Clearance
DUST SEAL
• Install the dust seal with the special tool.
$ 09913-70210: Bearing installer set (& 40)
The sealed cover of the bearing must face outside.
