SVAN 973 User Manual – Appendixes
142
Header of the statistical analysis - cf. Tab. B.1.14.
Header of the file from the logger - cf. Tab. B.1.15.
Contents of the file from the logger - cf. Tab. B.1.16. and the description in B.2.1.
B.2.1. The contents of the files in the logger
The records with the results and the records with the state of the markers as well as the records with the
breaks in the results registration are saved in the files in the logger. All results are written in dB*100.
B.2.1.1. Record with the results
The contents of the record with the results depends on the selected measurement function and the value
set in the LOGGER position of the PROFILE x and SPECTRUM sub-lists. The following elements can be
present (in the given sequence):
15 flag record
< flags > :
- b0: 1- the overload detected, 0 - the overload not detected
16 results of the measurement from the first profile if the corresponding LOGGER position was active
(paths: Measurement / Logging / Logger Res. / Prof. 1); up to seven words are written:
<result1> - Lxpeak
1
result, depending on the value of BufferP[1] (cf. Tab. B.1.12)
<result2> - Lxymax
2
result, depending on the value of BufferP[1] (cf. Tab. B.1.12)
<result3> - Lxymin
2
result, depending on the value of BufferP[1] (cf. Tab. B.1.12)
<result4> - Lxyeq
23
result, depending on the value of BufferP[1] (cf. Tab. B.1.12)
<result5> - LAV result, depending on the value of BufferP[1] (cf. Tab. B.1.12)
<result6> - LR15 result, depending on the value of BufferP[1] (cf. Tab. B.1.12)
<result7> - LR60 result, depending on the value of BufferP[1] (cf. Tab. B.1.12)
(3) results of the measurement from the second profile if the corresponding LOGGER position was
active (paths: Measurement / Logging / Logger Res. / Prof. 2); up to five words are written:
<result1> - Lxpeak
1
result, depending on the value of BufferP[2] (cf. Tab. B.1.12)
<result2> - Lxymax
2
result, depending on the value of BufferP[2] (cf. Tab. B.1.12)
<result3> - Lxymin
2
result, depending on the value of BufferP[2] (cf. Tab. B.1.12)
<result4> - Lxyeq
23
result, depending on the value of BufferP[2] (cf. Tab. B.1.12)
<result5> - LAV result, depending on the value of BufferP[2] (cf. Tab. B.1.12)
(4) results of the measurement from the third profile if the corresponding LOGGER position was active
(paths: Measurement / Logging / Logger Res. / Prof. 3); up to five words are written:
<result1> - Lxpeak
1
result, depending on the value of BufferP[3] (cf. Tab. B.1.12)
<result2> - Lxymax
2
result, depending on the value of BufferP[3] (cf. Tab. B.1.12)
<result3> - Lxymin
2
result, depending on the value of BufferP[3] (cf. Tab. B.1.12)
<result4> - Lxyeq
23
result, depending on the value of BufferP[3] (cf. Tab. B.1.12)
<result5> - LAV result, depending on the value of BufferP[3] (cf. Tab. B.1.12)
1
x - depends of the filter type for Peak result calculation in selected profile: A, C, Z, B (cf.
Tab. B.1.12)
2
x - depends of the filter type in selected profile: A, C, Z, B (cf. Tab. B.1.12)
