SVAN 973 User Manual – Appendixes
141
1
SubblockLength
2 * number of classes in the third profile + 2
2..3
Histogram[3][1]
the first counter in the third profile
4..5
Histogram[3][2]
the second counter in the third profile
.....
.....
.....
Table B.1.23. SETUP file
Word
number
Name
Comment
0
0x0020
[20, 00=block’s length in the second word]
1
BlockLength
length of the block
2..BlockL
ength-1
SetupTextData
saved setup values
Table B.1.24. File-end-marker
Word
number
Name
Comment
0
0xFFFF
file end marker
B.2 STRUCTURE OF THE FILE CONTAINING RESULTS FROM LOGGER’S FILE
SvanPC file header - cf. Tab. B.1.1.
File header - cf. Tab. B.1.2.
Unit and software specification - cf. Tab. B.1.3.
Calibration settings - cf. Tab. B.1.4.
USER’S text - cf. Tab. B.1.5.
Parameters and global settings - cf. Tab. B.1.6.
MEASUREMENT TRIGGER settings - cf. Tab. B.1.7.
LOGGER TRIGGER settings - cf. Tab. B.1.8.
Time-domain signal recording parameters - cf. Tab. B.1.9.
Wave-file recording parameters - cf. Tab. B.1.10.
Special settings for profiles - cf. Tab. B.1.12.
Display settings of the main results - cf. Tab. B.1.13.
