SVAN 973 User Manual – Appendixes
181
C.4 SPECIFICATION OF SV 973 AS 1/1 OCTAVE AND 1/3 OCTAVE ANALYZER
Statement of performance
SV 973 can operate as 1/1-octave or 1/3-octave analyser which meets requirements of the international
IEC 61260-1:2014 standard for the pass band filters for the Class 1 instruments. For sound analysis, its
accuracy results from the accuracy of the Sound Level Meter - see Chapters C.1 for specification.
Note: Simultaneously to the frequency analysis SV 973 operates as a Sound Level Meter - see
Chapters C.1 for specification.
Signal input
SV 973 microphone input throughout the SL 973 adapter
Maximum input voltage:
SV 973 meets the requirements of IEC 348 for the 2nd Class
devices. The input voltage shall not exceed the limits
between 0 V and +3 V.
SL 973 the input voltage shall not exceed the limits between -3 V
and +3 V.
Impedance:
SV 973 differential input: ≤ 94 k, ≤ 50 pF each.
SL 973 ≤ 10900 , ≤ 30 pF, single ended input.
Linear Operating Range
Table C.14 Linear operating range with SL 973
Weighting
Linear operating range (with 10 dB margin from noise)
(RMS for the sinusoidal signal at reference conditions @ 1 kHz,
0.0 dB calibration factor)
A
from 20.2 µV
RMS
to 1135 mV
RMS
B
from 20.2 µV
RMS
to 1135 mV
RMS
C
from 20.2 µV
RMS
to 1135 mV
RMS
Z
from 63.8 µV
RMS
to 1135 mV
RMS
Table C.15 Peak for the sinusoidal signal 1 kHz, at reference conditions with SL 973 (@ 128 dB Peak
indication)
Peak for the sinusoidal signal 1 kHz, at reference conditions
@ 1 kHz (0.0 dB calibration factor)
Weighting
Max Peak value
A
1.605 V
B
1.605 V
