SVAN 973 User Manual – Appendixes
<0xCAaa>
in which:
aa - size of records,
bb cc dd ee ff gg hh ii - 8-bytes name of wave file name
B.2.1.6. Record with Summary Results
The format of the data frame is as follows:
where:
HS starting header (1 word)
L length of the block (field is optional and occurs only when b7..b0 in header are set to zero)
D Summary Data:
- Main results (cf. Tab. B.1.17_SLM, B.1.17_DM)
- Statistical levels (optional, cf. Tab. B.1.18)
- 1/1 OCTAVE analysis results (optional, cf. Tab. B.1.19)
- 1/3 OCTAVE analysis results (optional, cf. Tab. B.1.20)
- The results of the statistical analysis in profiles(optional, cf. Tab. B.1.21)
HE ending header (1 word), which differs from the HS only on b11 bit (thanks to it, it is possible
to analyse the recorded file starting from its end)
The HEADER format is as follows:
where:
b15 - 1
b14 - 1
b13 - 0
b12 - 0,
b11 - header type:
0 - HS
1 - HE
b10 - 0
b9 - 1
b8 - 1
b15÷b8 – HS (0xC3), HE (0xCB)
b7÷b0 – length of the block (if zero length of the block is saved in additional word L)
B.2.1.7 Record with audio data
This record exists only in the case when the EVENT RECORDING function is active (path: Measurement
/ Logging / Event Rec.). Samples of the signal, taken in the periods from 1 second to 8 hours, are saved
in the blocks. Each block is divided into frames, which are stored in a file among the logger results. The
frame starting block and the frame ending it are marked with the set b10 and b9 bits in the header of the
frame, respectively. It happens in the case of stopping the recording that the ending frame does not exist.
