2.9 DOWNLOADING AND UPLOADING FILES
All measurement and setup files stored in the instrument’s memory can be downloaded to the PC with
the use of SvanPC++ or Supervisor software, which enables the user download and upload functions as
well as data view and data processing options. In this case, the instrument should be connected to the
PC via SC 158 USB-C cable.
SvanPC++ and Supervisor enable also uploading functions (usually for setup files).
Note: Working with SvanPC++ and Supervisor software is fully described in the documents:
“SvanPC++ User Manual” and “Supervisor User Manual”.
2.10 ACTIVATING OPTIONAL FUNCTIONS
Standard instrument firmware contains all basic functions to perform measurements in accordance with
most international standards and methods. For more complex tasks you may expand the instrument with
additional functions. These features include 1/1 and 1/3 octave analyser, wave recording and
reverberation time measurement.
If additional functions were not included in the instrument kit and were not unlocked by the supplier, such
a task is in responsibility of the user who decides to buy additional functions later.
The optional function is activated when you try to use it
for the first time. For example, if 1/1 Octave was locked,
but is purchased later, then during the first attempt to
switch it on, the instrument requires entering the special
code that will unlock this option. Once unlocked the
option is available permanently.
Pressing the <Shift> and ◄ keys right after turning on
the instrument enables checking and locking early
unlocked options.
To select other options, press the <Enter> key, which
opens another page of the Active Functions/Options
list.
