Chapter 6 Maintaining and Troubleshooting the TimeProvider
Troubleshooting the TimeProvider
166 TimeProvider User’s Guide 097-58001-02 Revision C – August 2005
EXDSC Excessive discontinuity fault Excessive discontinuity cleared
FFOFF FFOFF exceeded threshold FFOFF within threshold
MTIE MTIE exceeded threshold MTIE within threshold
TPIUSIG TPIU signal fault TPIU signal fault cleared
PRS and INP[p] Codes
INPDISQ Input disqualified as possible
reference
Input qualified as possible reference
INPAIS AIS fault AIS fault cleared
INPLOS LOS fault LOS fault cleared
INPOOF OOF fault OOF fault cleared
INPFRQ Frequency threshold exceeded Frequency within threshold
INPPHASE Phase error exceeded threshold Phase error within threshold
INPQL Quality Level (SSM) exceeded
threshold
Quality Level (SSM) within threshold
INPTRR Tip/ring reversal on input Tip/ring connection correct
EXDSC Excessive discontinuity fault Excessive discontinuity cleared
MTIE MTIE exceeded threshold MTIE within threshold
OUT[g] Codes
OUTFAIL Output fault Output fault cleared
SYNTHEOR
Output generator exceeds pull-in range
Output generator within pull-in range
SYNTHFAIL Output generator failed Output generator restored
RTMg[-p] Alarm Conditions
S1LOS Side 1 LOS fault Side 1 LOS fault cleared
S2LOS Side 2 LOS fault Side 2 LOS fault cleared
EXSLIP Slip rate threshold exceeded Slip rate within threshold
FRMFAULT Retimer module has a fault Retimer module fault has cleared
Table 6-6. Set and Clear Conditions for Alarms
Alarm ID Set Alarm Conditional Description Clear Alarm Conditional Description
