Page #192 background imageLoading...
Page #192 background image
Chapter 7 Specifications of the TimeProvider
T1 Retimer
192 TimeProvider User’s Guide 097-58001-02 Revision C – August 2005
T1 Retimer
The T1 Retimer module has the following specifications:
CC Signals
Amplitude 2.7 to 3.3 V
p
Termination Impedance 133 ± 5% balanced
JCC Signals
Amplitude 1.0 V
p
±0.1 V
Termination Impedance 110 balanced
JCC4 Signals
Amplitude 1.0 V
p
±0.1 V
Termination Impedance 110 balanced
8k Signals
Amplitude 4 V p-p ± 10%
Termination Impedance 100 balanced
1.544 MHz Signals
Amplitude 0 dBm ± 3 dB
Termination Impedance 75 unbalanced
6.312 MHz Signals
Amplitude 0 dBm ± 3 dB
Termination Impedance 75 unbalanced
Table 7-5. T1 Retimer Specifications
Parameter Specification
Specifications ANSI T1.101 and Telcordia GR-1244
Input Amplitude Range +3 to –24 dB DSX
Termination Impedance 100 ±5% balanced
Table 7-4. Output Signal Specifications (Continued)
Parameter Specification
