097-58001-02 Revision C – August 2005 TimeProvider User’s Guide 45
Chapter 2 Engineering and Ordering Procedures
GPS Antenna
GPS Antenna
The following table identifies the parts available for the GPS antenna.
Table 2-4. GPS Parts and Accessories
Part Number Description
990-58545-01 TimeProvider Integrated GPS Antenna Kit, Rear Access
990-58545-02 TimeProvider Integrated GPS Antenna Kit, Front Access
090-58545-01 TimeProvider GPS Antenna
090-58545-21 TPIU for Front or Rear Access shelf
060-58543-03
060-58543-10
060-58543-20
060-58543-50
Front Access TPIU Interconnect cable, 1 m (3 ft)
Front Access TPIU Interconnect cable, 3 m (10 ft)
Front Access TPIU Interconnect cable, 6 m (20 ft)
Front Access TPIU Interconnect cable, 15 m (50 ft)
060-58544-03
060-58544-10
060-58544-20
060-58544-50
Rear Access TPIU Interconnect cable, 1 m (3 ft)
Rear Access TPIU Interconnect cable, 3 m (10 ft)
Rear Access TPIU Interconnect cable, 6 m (20 ft)
Rear Access TPIU Interconnect cable, 15 m (50 ft)
060-58545-01
1
060-58545-02
1
060-58545-05
060-58545-10
060-58545-20
060-58545-30
060-58545-50
060-58545-60
060-58545-80
060-58545-99
Note:
1
These lengths are to be used only between the TimeProvider antenna and
lightning suppressor.
RG-58 cable, 3 m (10 ft)
RG-58 cable, 6 m (20 ft)
RG-58 cable, 15 m (50 ft)
RG-58 cable, 30 m (100 ft)
RG-58 cable, 60 m (200 ft)
RG-58 cable, 90 m (300 ft)
RG-58 cable, 150 m (500 ft)
RG-58 cable, 180 m (600 ft)
RG-58 cable, 240 m (800 ft)
RG-58 cable, 300 m (1000 ft)
154-00023-01 Crimp tool for RG-58 cable
371-001 TNC connectors for RG-58 cable
