Chapter 2 Engineering and Ordering Procedures
Ordering and Parts List
46 TimeProvider User’s Guide 097-58001-02 Revision C – August 2005
Ordering and Parts List
All IOCs, IMCs, and Input and Output Connector modules are sold separately. Use
Table 2-5 to identify the available TimeProvider shelf types.
Accessories, Tools, and Equipment
You need to supply the following tools and materials for installing and testing the
TimeProvider:
îš„ Phillips-head screwdriver for installing the TimeProvider shelf in a rack
îš„ ESD wrist strap for installing cards
îš„ Digital multimeter (Fluke 77 or equivalent) for verifying power connections to the
shelf
îš„ Laptop computer with communications software such as HyperTerminal,
ProComm Plus, etc. for provisioning the TimeProvider
îš„ (Optional) Dual-channel oscilloscope with 100 MHz minimum bandwidth for
verifying that clock input and output signal(s) are within the specified voltage
range, and for checking output waveforms
îš„ DB-9 M to DB-9 F cable for connecting to the local Craft port
îš„ DB-25 M connector for alarms
îš„ Soldering iron and solder and appropriate cable for building power and alarm
connectors
Table 2-5. TimeProvider Shelves
Model Outputs Part Number
1000
Front Access Main Shelf
8 to 32
(1 to 4 Output Connector modules)
990-58001-01
1000
Front Access Expansion Shelf
8 to 64
(1 to 8 Output Connector modules)
990-58002-01
1100
Rear Access Main Shelf
8 to 32
(1 to 4 Output Connector modules)
990-58101-01
1100
Rear Access Expansion Shelf
8 to 64
(1 to 8 Output Connector modules)
990-58102-01
