Page #60 background imageLoading...
Page #60 background image
Chapter 3 Installing the TimeProvider
Making Connections
60 TimeProvider User’s Guide 097-58001-02 Revision C – August 2005
Making Output Connections
You make the output signal connections using one of the Output modules listed in
Table 3-4. Attach the module to the shelf before you connect cables.
Installing the Output Module
Attach the Output module to the shelf and secure it using the screws at the top and
bottom of the module.
Table 3-5 lists the pinout for the DB9 Output module, which is shown in Figure 3-13.
Table 3-4. Output Connector Modules
Item Number Description Reference
090-58091-01 BNC Output module Figure 3-12
090-58091-02 Wire-wrap Output module Figure 3-12
090-58091-03 DB9 Output module Figure 3-13
090-58091-04 SMZ/BT43 Output module Figure 3-13
090-58091-05 Metric (Siemens) 1.0/2.3 Output
module
Figure 3-14
090-58091-06 Metric (Siemens) 1.6/5.6 Output
module
Figure 3-14
090-58081-02 T1 Retimer Output module (wire-wrap) Figure 3-14
090-58082-01 E1 Retimer Output module (BNC) Not shown
090-58082-06 E1 Retimer Output module (Siemens
1.6/5.6)
Not shown
Table 3-5. Pinout for the DB9 Output Module
Pin Description
1Port A Tip
2 Port A Ring
4, 5, and 6 Chassis Ground
8Port B Tip
9 Port B Ring
