1 GENERAL INFORMATION
1.1 User Manual Content
This User’s Manual contains the operating instructions, installation instructions and
specifications of the Genesys™ 750W and 1500W power supply series. The instructions
refer to the standard power supplies, including the built-in RS232/RS485 serial
communication.
1.2 Introduction
1.2.1 General Description
Genesys™ power supplies are wide output range, high performance switching power
supplies. The Genesys™ series is power factor corrected and operates from worldwide
AC voltage range continuously. Output Voltage and Current are continuously displayed
and LED indicators show the complete operating status of the power supply. The Front
panel controls allow the user to set the output parameters, the protections levels (Over-
Voltage protection, Under-Voltage limit and Foldback) and preview the settings. The rear
panel includes the necessary connectors to control and monitor the power supply
operation by remote analog signals or by the built-in serial communication
(RS232/RS485). GPIB programming and Isolated-Analog programming/monitoring are
optional.
1.2.2 Models Covered by this Manual
Model
Voltage range
(V)
Current range
(A)
Model
Voltage
range (V)
Current
range (A)
GEN 6-100
0 - 6
0 - 100
GEN 60-12.5
0 - 60
0 - 12.5
GEN 6-200
0 - 6
0 - 200
GEN 60-25
0 - 60
0 - 25
GEN 8-90
0 - 8
0 - 90
GEN 80-9-5
0 - 80
0 - 9.5
GEN 8-180
0 - 8
0 - 180
GEN 80-19
0 - 80
0 - 19
GEN 12.5-60
0 - 12.5
0 - 60
GEN 100-7.5
0 - 100
0 - 7.5
GEN 12.5-120
0 - 12-5
0 - 120
GEN 100-15
0 - 100
0 - 15
GEN 20-38
0 - 20
0 - 38
GEN 150-5
0 - 150
0 - 5
GEN 20-76
0 - 20
0 - 76
GEN 150-10
0 - 150
0 - 10
GEN 30-25
0 - 30
0 - 25
GEN 300-2.5
0 - 300
0 - 2.5
GEN 30-50
0 - 30
0 - 50
GEN 300-5
0 - 300
0 - 5
GEN 40-19
0 - 40
0 - 19
GEN 600-1.3
0 - 600
0 - 1.3
GEN 40-38
0 - 40
0 - 38
GEN 600-2.6
0 - 600
0 - 2.6
GEN 50-30
0 - 50
0 - 30
Table 1-1: Models Covered by the Manual
