2 SPECIFICATIONS
2.1 OUTPUT RATING
MODEL
GEN
6-100
8-90
12.5-60
20-38
30-25
40-19
–
60-12.5
80-9.5
100-7.5
150-5
300-2.5
600-1.3
1.Rated output voltage (*1)
V
6
8
12.5
20
30
40
–
60
80
100
150
300
600
2.Rated output current 750W (*2)
A
100
90
60
38
25
19
–
12.5
9.5
7.5
5
2.5
1.3
3.Rated output power 750W
W
600
720
750
760
750
760
–
750
760
750
750
750
780
MODEL
GEN
6-200
8-180
12.5-120
20-76
30-50
40-38
50-30
60-25
80-19
100-15
150-10
300-5
600-2.6
1.Rated output voltage (*1)
V
6
8
12.5
20
30
40
50
60
80
100
150
300
600
2.Rated Output Current 1500W (*2)
A
200
180
120
76
50
38
30
25
19
15
10
5
2.6
3.Rated output power 1500W
W
1200
1440
1500
1520
1500
1520
1500
1500
1520
1500
1500
1500
1560
2.2 INPUT CHARACTERISTICS
V
6
8
12.5
20
30
40
50
60
80
100
150
300
600
1. 1. Input voltage/freq. (*3)
–
85-265Vac continuous, 47-63Hz, single phase.
2. 2.Input current (at 100/200Vac)
A
10.5/5 for 750W model, 21/11 for 1500W models.
3. 3.Power Factor
–
0.99@100/200Vac, rated output power.
4. 4.750W models Efficiency (*4)
%
76/78
77/80
81/84
82/85
82/85
83/87
--
83/87
83/87
83/87
83/87
83/87
83/87
5. 5.1500W models Efficiency (*4)
%
77/79
78/81
82/85
83/86
83/86
84/88
84/88
84/88
84/88
84/88
84/88
84/88
84/88
6. 6.Inrush current at 100/200V
A
Less than 25A for 750W models, 50A for 1500W models.
2.3 CONSTANT VOLTAGE MODE
V
6
8
12.5
20
30
40
50
60
80
100
150
300
600
1. 1.Max.Line regulation (*5)
–
0.01% of rated output voltage +2mV
2. 2.Max.Load regulation (*6)
–
0.01% of rated output voltage +2mV
3. 3.Ripple and noise (p-p,20MHz) (*10)
mV
60 60 60 60
60
60
60
60
60
60
60
80 80 100 150
80
100
150
300
4. 4.Ripple r.m.s., 5Hz-1MHz (*10)
mV
8 8 8 8 8 8 8 8
8
8
8
8
8
8
8
8 8 10 25
8
10
25
60
5. 5.Temperature coefficient
PPM/°C
100PPM/°C of rated output voltage, following 30 minutes warm up
6. 6.Temperature drift
–
0.05% of rated Vout over 8hrs interval following 30 minutes warm-up. Constant line, load & temp.
7. 7.Rem. Sense compensation/wire
V
1 1 1 1 1.5 2 2 3
1
1
1
1.5
2
2
3
4 5 5 5
5
5
5
5
8. 8.Up-prog. Response time 0-Vomax (*9)
mS
80
150
250
9. 9.Down-prog. Response time: Full load
mS
10
50
80
150
250
No load
mS
500 600 700 800 900 1000 1100 1100
600
700
800
900
1000
1100
1100
1200 1500 2000 2500
1500
2000
2500
4000
10. 10.Transient response time
mS
Time for the output voltage to recover within 0.5% of its rated output for a load change 10-90% of
rated output current.
Output set-point: 10-100%.
Less than 1mS for models up to and including 100V; 2mS for models above 100V.
11. 11.Hold-up time
mS
More than 20mS, 100Vac, rated output power.
2.4 CONSTANT CURRENT MODE
V
6 8 12.5 20 30 40 50 60 80 100
8
12.5
20
30
40
50
60
80
100
150
300
600
1. 1.Max.line regulation (*5)
–
0.01% of rated output voltage +2mA
2. 2.Max.load regulation (*7)
–
0.02% of rated output current +5mA
3. 3.Ripple r.m.s. 5Hz-1MHz.750W (*8)
mA
200 180 120 76 63 48 – 38 29 23
180
120
76
63
48
--
38
29
23
18
13
8
1500W (*8)
mA
400
360
240
152
125
95
85
75
57
45
35
25
12
4. 4.Temperature coefficient
PPM/°C
100PPM/°C from rated output current, following 30 minutes warm-up.
5. 5.Temperature drift
–
0.05% of rated lout over 8hrs interval following 30 minutes warm-up. Constant line, load & temp.
6. 6.Warm up drift
–
Less than 0.1% rated output current over 30 minutes following power on or output voltage change
or load current change.
2.5 ANALOG PROGRAMMING AND MONITORING
1.Vout voltage programming
–
0-100%, 0-5V or 0-10V, user select. Accuracy and linearity; +/-0.5% of rated Vout.
2. Iout voltage programming
–
0-100%, 0-5V or 0-10V, user select. Accuracy and linearity; +/-1% of rated Iout.
3. Vout resistor programming
–
0-100%, 0-5/10Kohm full scale, user select. Accuracy and linearity: +/-1% of rated Vout.
4. Iout resistor programming
–
0-100%, 0-5/10Kohm full scale, user select. Accuracy and linearity: +/-1.5% of rated Iout.
5. On/off control
–
By electrical Voltage: 0-0.6V/2-15V or dry contact, user selectable logic.
6. Output current monitor
–
0-5V or 0-10V, user selectable. Accuracy: 1%
7. Output voltage monitor
–
0-5V or 0-10V, user selectable. Accuracy: 1%
8. Power supply OK signal
–
4-5V-OK, 0V-Fail, 500ohm series resistance.
9. Parallel operation
–
Possible, up to 4 units in master/slave mode with single wire current balance connection.
10. Series operation
–
Possible (with external diodes), up to 2 units.
11. CV/CC indicator
–
Open collector. CC mode: On, CV mode: Off. Maximum voltage: 30V, maximum sink current: 10mA
12. Enable/Disable
–
Dry contact. Open: off, Short: on. Max. voltage at Enable/Disable in: 6V.
13. Local/Remote analog control
–
By electrical signal or Open/Short: 0-0.6V or short: Remote, 2-15V or open: Local.
14. Local/remote analog indicator
–
Open collector. Local: Open, Remote: On. Maximum voltage: 30V, maximum sink current: 5mA.
