6.5 Resistive Programming of Output Voltage and Current Limit
For resistive programming, internal current sources, for Output Voltage and/or Output
Current control, supply 1mA current through external programming resistors connected
between J1-9 & 22 and J1-10 & 23. The voltage across the programming resistors is used
as a programming voltage for the power supply. Resistance of 05Kohm or 010Kohm can
be selected to program the Output Voltage and Output Current from zero to full scale.
A variable resistor can control the output over its entire range, or a combination of variable
resistor and series/parallel resistors can control the output over restricted portion of its
range.
Perform the following procedure to set the power supply to Resistive programming:
1. Turn the AC On/Off switch to Off.
2. Set setup switch SW1, positions 1 and 2 to their UP position.
3. Set SW1, position 3 to select the programming resistor range according to Table 6-4.
4. Set SW1, positions 7 and 8 to their UP position, to enable resistive programming mode.
5. Connect a wire jumper between J1-8 and J1-12 (refer to Table 4-4).
6. Connect the programming resistors to the mating plug of J1 as shown in Fig.6-2.
7. Set the programming resistors to the desired resistance and turn the power supply ON.
Adjust the resistors to change the power supply output.
NOTES:
1. SW1, positions 4, 5, 6 and 9 are not required for remote programming. Their settings
can be determined according to the application requirements.
2. The control circuits allow the user to set the Output Voltage and Output Current up to
5% over the model-rated maximum value. The power supply will operate within the
extended range, however, it is not recommended to operate the power supply over its
voltage and current rating and performance is not guaranteed.
3. To maintain the temperature stability specification of the power supply, the resistors
used for programming should be stable and low noise resistors, with temperature
coefficient of less than 50ppm.
4. When resistive programming is used, front panel and computer control (via serial
communication port) of Output Voltage and Current are disabled.
Output Voltage programming
VPGM (J1-9)
Output Current programming
IPGM (J1-10)
Table 6-4: SW1-3 setting and programming range
