34
83507013 Rev G
3 INSTALLATION
3.1 General
This Chapter contains instructions for initial inspection, preparation for use and repackaging
for shipment. Connection to PC, setting the communication port and linking Genesys™
power supplies are described in Chapter 7.
NOTE
Genesys
TM
power supplies generate magnetic fields which might affect
the operation of other instruments. If your equipment is susceptible to
magnetic fields, do not position it adjacent to the power supply.
3.2 Preparation for Use
In order to be operational, the power supply must be connected to an appropriate AC
source. The AC source voltage should be within the power supply specification. Do not
apply power before reading Section 3.6 and 3.7.
Table 3-1 below, describes the basic setup procedure. Follow the instructions in Table 3-1 in
the sequence given to prepare the power supply for use.
Initial physical inspection of the power supply
Installing the power supply, ensuring adequate ventilation.
AC source requirements connecting the power supply to the
AC source
Turn-on checkout procedure.
Wire size selection; Local/Remote sensing; Single or multiple
loads.
The power supply setting at shipment.
Table 3-1: Basic Setup Procedure
3.3 Initial Inspections
Prior to shipment this power supply was inspected and found free of mechanical or electrical
defects. Upon unpacking of the power supply, inspect for any damage which may have
occurred in transit.
The inspection should confirm that there is no exterior damage to the power supply such as
broken knobs or connectors and that the front panel and meter faces are not scratched or
cracked. Keep all packing material until the inspection has been completed. If damage is
detected, file a claim with carrier immediately and notify the TDK-Lambda Americas Inc.
sales or authorized service facility nearest you.
