4.4.1 SW1 Position Function
Refer to Table 4-3 for description of SW1 position functions. The factory default setting
is Down for all positions.
Table 4-3: SW1 Positions Functions
Position
Function
DOWN (Factory default)
UP
SW1-1
Output Voltage
Remote Analog
Programming
Output Voltage
programmed by Front
Panel
Output Voltage programmed by remote
analog External Voltage or External
Resistor
SW1-2
Output Current Remote
Analog programming
Output Current
programmed by Front
Panel
Output Current programmed by remote
analog External Voltage or External
Resistor
SW1-3
Programming Range Select
(Remote voltage/resistive)
0-5V/(0-5Kohm)
0-10V/(0-10Kohm)
SW1-4
Output Voltage and
Current Monitoring Range
0-5V
0-10V
SW1-5
Shut-Off Logic select
Off: Low (0-0.6V) or Short
On: High (2-15V) or Open
Off: High (2-15V) or Open
On: Low (0-0.6V) or Short
SW1-6
RS232/485 select
RS232 interface
RS485 interface
SW1-7
Output Voltage
Resistive Programming
Output Voltage
programmed by Front
Panel
Output Voltage
programmed by
External resistor
SW1-8
Output Current
Resistive Programming
Output Current
Programmed by Front
Panel
Output Current Programmed by
External Resistor
SW1-9
Enable/Disable control
Rear panel Enable/Disable
control is not Active
Rear panel Enable/Disable control
is Active
4.4.2 Resetting the SW1 Switch
Before making any changes to the SW1 switch setting, disable the power supply output
by pressing the front panel OUT button. Ensure that the Output Voltage falls to zero and
the OUT LED is Off. Then use any small flat-bladed screwdriver to change the SW1
switch setting.
4.5 Rear Panel J1 Programming and Monitoring Connector
The J1 Programming and Monitoring connector is a DB25 subminiature connector located
on the power supply rear panel. Refer to Table 4-4 for description of the connector
functions. The power supply default configuration is Local operation, which does not require
connections to J1. For remote operation using J1 signals, use the plug provided with power
supply (or equivalent type). It is essential to use a plastic body plug to conform to Safety
Agency requirements. If a shield is required for the J1 wires, connect the shield to a power
supply chassis ground screw.
