4-6-4-2-7. Maximum/minimum
The maximum and minimum load values are detected when measurement values are in the zone.
At the moment that the load difference × scaling factor occurs the number of times set for the detection count, the points when the
maximum and minimum values occurred will become the hold points.
OFF
ON
HI
OFF
ON
LO
Load
Judgment output (load/displacement)
Zone interval
Time or displacement
Load
difference
Maximum Minimum
Load difference × scaling factor,
detection count realized
Judgment output (load/displacement)
If the hold point meets a HI or LO condition, this becomes ON.
If the hold point is within the management value range, judgment for this zone will be OK.
4. Settings
