76
6-1-2-7. Work
Content Command No. Setting item
Work number 7000 1–16 (enabled only during manual selection)
Switch work (WORK SWITCHING) 7001 0: Manually, 1: External input (EXT. INPUT)
Copy work 7002 0: All, 1–16: Work number
Measurement
trigger
Measurement starting condition 7003 0: EXT. SIGNAL, 1: EXT. & LOAD, 2: EXT. & DISP.
Measurement starting level 7004 ±99999
Measurement stopping condition 7005
0: EXT. SIGNAL, 1: EXT. OR LOAD (EXT. | LOAD),
2: EXT. OR DISP. (EXT. | DISP.), 3: EXT. OR TIME (EXT. | TIME)
Measurement stopping level 7006 ±99999
Continuous
judgment
Enable HHLL 7010 0: Disabled, 1: Enabled
HH 7011 ±99999
HI 7012 ±99999
LO 7013 ±99999
LL 7014 ±99999
Band judgment
Enable/Disable waveform comparison
(WAVEFORM COMP.)
7100
0: Disabled, 1: Enabled
o If no reference waveform has been set, it will not
become enabled.
Zone judgment
Zone switching 7101 0: Preset, 1: External input
Indicator value display (INDICATOR VALUE) 7102 0: Input value, 1–5: Zone number
Zone parameters
Set zone number 7200
1–5 (resets to 1 when power turned on/off)
o The zone set by this can be changed with the
following commands.
Enable zone 7201 0: Disabled, 1: Enabled
Zone range starting point 7202 ±99999
Zone range ending point 7203 ±99999
Load high limit (HI) 7204 ±99999
Load low limit (LO) 7205 ±99999
Displacement high limit (HI) 7206
±99999
o This can be set when the X axis is set to
displacement.
Displacement low limit (LO) 7207
±99999
o This can be set when the X axis is set to
displacement.
Judgment method 7208
0: Constant comparison, 1: Sample, 2: Peak, 3: Bottom,
4: Peak-to-peak, 5: Average value, 6: Maximum,
7: Minimum, 8 Inflection point
Load difference
(LOAD DIF.)
7211 ±99999
Scaling factor 7212 00–99 (input without decimal point) (0.0–9.9)
Number of detections
(COUNT)
7213 1–10
Inflection point
(INFLECTION)
Detection starting
load (STARTING LOAD)
7220 ±99999
Detection extent A
(WIDTH A)
7221 1–9999
Detectio extent B
(WIDTH B)
7222 1–9999
Load difference
(LOAD DIF.)
7223 ±99999
Offset extent
(OFFSET)
7224 0–99
6. Communication functions
