5.3.4.3.12.9 SIM PIN (CMR)
Display (e.g.):
Here the up to six digits SIM PIN of the used SIM card (not in scope of delivery) of the
Internet Service Provider (ISP) has tob e input. The PIN can be seen from the contract
documents of the ISP. If no PIN is required, the input field has to be left empty.
5.3.4.3.12.10 Access Point Name (CMR)
Display (e.g.):
This is the place where the Access Point Name (APN) of the chosen Internet Service
Provider (ISP) for internet access has to be input. The APN can be seen from the ISP
contract documents. If this is not the case, contact ISP support.
An alphanumeric character string containing up to 63 characters can be entered (cf.
chapter 5.1.1). With more than 15 characters the text scrolls out of the display to the
left.
5.3.4.3.12.11 User name (CMR)
Display (e.g.):
In order to connect to the Access Point Name (APN) some Internet Service Providers
(ISP) demand user data. Here the user name can be input if required. The User name
can be seen from the ISP contract documents. If this is not the case, contact ISP sup-
port. If no user name is required, the input field can be left empty.
An alphanumeric character string containing up to 31 characters can be entered (cf.
chapter 5.1.1). With more than 15 characters the text scrolls out of the display to the
left.
5.3.4.3.12.12 Password (CMR)
Display (e.g.):
In order to connect to the Access Point Name (APN) some Internet Service Providers
(ISP) demand user data. Here the password can be input if required. The password can
be seen from the ISP contract documents. If this is not the case, contact ISP support. If
no password is required, the input field can be left empty.
An alphanumeric character string containing up to 31 characters can be entered (cf.
chapter 5.1.1). With more than 15 characters the text scrolls out of the display to the
left.
SIM PIN:
12345
Access Point:
nternet.telekom
User:
t
-
mobile
Password:
tm
