3 - Technical Data
Technical Data
Te-Stack Operating Manual, 391862, en, V2.3 3 - 7
Options
The following options are available for the Te-Stack:
Also see section 3.4 “Options”,  3-11.
3.2 Technical Data
3.2.1 Dimensions and Weights
All Te-Stack versions Base unit for 1 stacker column
Stacker columns for microplates, DiTi racks or DiTi
boxes (LiHa or Te-MO/MCA access)
Tool Reference plate
Tab. 3-2 Options for the Te-Stack
Barcode scanner Freedom EVO version
Waste station Freedom EVO version
Waste chute Freedom EVO version
Waste chute Freedom EVO version
Nested DiTi waste station Freedom EVO version
Nested DiTi transfer slide Freedom EVO version
Tab. 3-1 Necessary components of the Te-Stack (basic) configuration (cont.)
Tab. 3-3 Physical specifications of versions (weight and dimensions)
Weight
(kg/lbs)
Dimensions
(Depth x Width x Height)
Te-MO version (equipped
with 3 Te-Stack base units
and 3 stacker columns)
28 kg
(62 pounds)
200 mm x 590 mm x 840 mm
(7.9 in. x 3.6 in. x 33.1 in.)
Freedom EVO version
(equipped with 2 transfer sta-
tions, 2 slides, 4 Te-Stack
base units, and 4 stacker col-
umns)
69 kg
(153 pounds)
504 mm x 606* mm x min. 900 mm*
(19.9 in. x 23.9 in. x min. 35.5 in.)
The transfer station can overlap at
the outer side up to 125 mm (5.0
in.).
