3 - Technical Data
Options
Te-Stack Operating Manual, 391862, en, V2.3 3 - 11
3.4 Options
3.4.1 Waste Station and Waste Chute (Options)
Freedom EVO version: Waste station, waste chute for automated disposal of
microplates or DiTi boxes.
3.4.2 Barcode Scanner (Option)
Freedom EVO version: Available for transfer stations (mounted at the left or the
right side in top or bottom position).
A maximum of 4 barcode types can be read at the same time.
Fig. 3-8 Freedom EVO version waste stations (A) and waste chute (B)
B
A1
A1
A2
A2
A1 Waste stations
A2 Waste station nested DiTi
B Waste chute
Fig. 3-9 Barcode scanner (item A: example top position)
A
