tecan Te-Stack 10612253 - Refilling Stacker Column for Diti Boxes; Emptying the Diti Waste (Te-MO Version Only)

6 - 6 Te-Stack Operating Manual, 391862, en, V2.3
6 - Operation
Tasks During a Run
ATTENTION
Risk of damage to equipment. Removing stacker column loaded with nested DiTi
will lead to damage to DiTi.
 Install the carrier slide before removing the column.
Or
 Remove all nested DiTi stacks form the columns before removal.
Fill the microplates or the DiTi racks from the top into the stacker column.
6.5.3 Refilling Stacker Column for DiTi Boxes
ATTENTION
Compatibility.
 A stacker column for DiTi boxes cannot be used for microplates.
 DiTi boxes always have to be used without lid.
Fill the DiTi boxes from the top into the stacker column.
6.5.4 Emptying the DiTi Waste (Te-MO Version Only)
1 Click the Pause button.
2 Replace the full waste bag by an empty one.
3 Fix the waste bag.
4 Click the Continue button.
Fig. 6-3 Overview of Freedom EVO version in front position
