tecan Te-Stack 10612253 - Electrical Specifications (Supply); Performance Data

3 - 8 Te-Stack Operating Manual, 391862, en, V2.3
3 - Technical Data
Technical Data
3.2.2 Electrical Specifications (Supply)
3.2.3 Performance Data
Tab. 3-4 Physical specifications of components (weight and dimensions)
Weight
(kg/lbs)
Dimensions
(Depth x Width x Height)
Te-Stack support for Te-MO 3.8 kg
(8½ pounds)
163 mm x 590 mm x 400 mm
(6.5 in. x 23.3 in. x 15.8 in.)
Te-Stack worktable exten-
sion
13.3 kg
(29½ pounds)
504 mm x 606 mm x min. 94 mm
(19.9 in. x 23.9 in. x min. 3.7 in.)
Base unit support for front
mounting
4.6 kg
(10 pounds)
85 mm x 600 mm x 405 mm
(3.4 in. x 23.7 in. x 16.0 in.)
Base unit support for rear
mounting
8.6 kg
(18½ pounds)
85 mm x 600 mm x 410 mm
(3.4 in. x 23.7 in. x 16.2 in.)
Transfer station 3.0 kg
(6½ pounds)
100 mm x 764 mm x 60 mm
(4.0 in. x. 30.0 in. x 2.55 in.)
Te-Stack base unit 5.2 kg
(11½ pounds)
155 mm x 182 mm x 380 mm
(6.1 in. x 7.2 in. x 15.0 in.)
Stacker columns for micro-
plates, DiTi racks or DiTi
boxes
2.8 kg
(6¼ pounds)
145 mm x 167 mm x 685 mm
(5.7 in. x 6.6 in. x 27.0 in.)
Tab. 3-5 Electrical specifications (Supply)
Freedom EVO, Genesis RWS and Genesis
Freedom
Voltage 24 V DC
Consumption 100 W (approx. 4 A)
Connecting cable CAN port / power
Connnector(s) D-Sub 9 pole male
Equipment safety class 1
Tab. 3-6 Performance
Throughput Max. 5 s. for 1 microplate (get and drop)
