3 - Technical Data
Technical Data
Te-Stack Operating Manual, 391862, en, V2.3 3 - 9
3.2.4 Supported Microplates
3.2.5 Stacker Column Capacity
Tab. 3-7 Supported microplates
Types 96, 384, 1536 wells microplates, deep well plates.
The Microplates must meet the SBS standard 2001.
Refer to chapter 4.4.1 “Microplates”,  4-10.
Height 8 - 42 mm (0.3135 to 1.654 in.)
Tab. 3-8 Stacker column capacity
Microplate height Number of microplates
8 mm/0.315 in. 80
14 mm/0.551 in. 40
42 mm/1.654 in. 13
LiHa DiTi length
a)
a) DiTis for LiHa access
Number of DiTi boxes
39 mm/1.535 in. (50 µl) 28
52 mm/2.047 in. (100/200 µl) 10
100 mm/3.937 in. (1000 µl) 7
Te-MO/MCA DiTi box height
b)
b) DiTis for multichannel head (Te-MO and MCA) access
Number of DiTi boxes
55.6mm/2.189 in. (DiTi box with 50 µl DiTis) 12
55.6mm/2.189 in. (DiTi box with 100 µl DiTis) 12
55.6mm/2.189 in. (DiTi box with 200 µl DiTis) 12
Nested DiTi inserts
(Distance between inserts 16.1mm)
40
