Technogym CROSS PERSONAL - TROUBLESHOOTING

CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 3.5
3.2.6. AUDIO/VIDEO EXTERNAL DEVICE CONNECTOR BOARD
The board is positioned at the bottom of the lower guard of the equipment and makes available
some connectors for connecting Audio / Video source and the external display on the base-band of
LCD.
3.2.7. JACK CUFFIE
The machine display has one jack for connecting headphones. The jack is connected on a stereo
output of the CPU Board.
3.2.8. SCHEDA C-SAFE (INTEGRATA)
It 'a function that allows the connection using a appropriate cable for connecting other devices, such
as: external PC suitably, programmed to control the machine (speed, level of difficulty, etc ...)
3.2.9. PORTA USB DI SERVIZIO (INTEGRATA)
It is used to connect USB keys for updates: High Kit, Low Kit, Digital TV Board, Dual TGS reader
and the transfer of Radio and TV channels, from one VISIO device to another.
3.2.10. CAPACITIVE TOUCH SCREEN CONTROL BOARD
It’s the board that manages the Touch Screen through 2 flat cables and connect it to the CPU board.
The board includes the following 2 LEDs indicator:
LED name
Colour
Description
LED 1
GREEN
It light up when switch ON the machine then immediately
turn off; it light up again every time you press on the Touch
Screen.
LED 2
RED
If ON the power supply reaches the board.
If OFF the power supply does not reach the board.
ATTENTION: If the Green LED blinks continuously without anyone touching the
Touch Screen, this might be because the capacitive Touch Screen control board is
affected by interference from either the network supplying the machine, or from other
outside sources such as: amplifiers, PCs, USB accessories, etc…
3.2.11. POWER SUPPLY BOARD
The Power Supply board isolates the high voltage between the input Module and the Brake Board
and is controlled via the infra-red Start switch on the column, which changes the status of the relay
switch. It consists of two zones: one dedicated to the switching power supply; the second consists
of relay switch dedicated to supplying power to the Brake Board and which consequently powers
the equipment.
