2.10. CABLES
The colour of the cables can be changed, refer in particular to the Pin Out.
2.10.1. CBQ CABLES
CBQ32: TGS cable
(Patch conn.– CPU Board)
CPU Board
CN19
Signal Colour Patch conn.
1
+12 Vdc power supply
Red
8
3
Rx
Brown
1
5
Tx
Blue
2
9
Gnd
Black
6
2.10.2. WB CABLES
WB657: Flat Tuner Board cable
(CPU Board –TUNER Board)
CPU Board
J9
Signal
TUNER Board
J13
1
Capacitive Signal
flat
…50
Capacitive Signal
flat
2.10.3. CU CABLES
CU132: TGS signal cable
(Patch conn. –TGS Dual reader)
Patch conn. Signal Colour
TGS Dual reader
CN1
8
+12Vdc power supply
Black
2
1
RX
Green
1
2
TX
Black
4
6
GND
Black
5
