Technogym CROSS PERSONAL - SCHEDULED MAINTENANCE

CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 7.9
7.9. DISMANTLING THE TWEETER FROM THE TOTAL
LEVER
OPERATION
DESCRIPTION
Dismantling the tweeter
from the Total Lever
1.
Remove the top end cap from the Total lever and the tweeter
cover. Unscrew the screws, using a 2.5 mm hex key.
2.
Unscrew the 2 screws anchoring the tweeter support, using a
Phillips screwdriver.
3. Remove the tweeter.
