Technogym CROSS PERSONAL - Dismantling the Low Kit, Power Card, Brake and Flywheel

CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 7.16
7.16. DISMANTLING THE LOW KIT, POWER CARD, BRAKE
AND FLYWHEEL
OPERATION
DESCRIPTION
Dismantling the Low Kit,
Power Card, Brake and
Flywheel
On the left-hand side of the equipment
1. Disconnect the platform lever from the crank (see “Platform
Lever” dismantling procedure).
2. Remove the crank guard cover.
3. Unscrew the 2 screws anchoring the round "mirror-finish" guard
to the frame, using a 4 mm hex key.
4. Remove the side guard coverin
g the mechanics assembly (see
“Rear guard” dismantling procedure).
5. It is now possible to remove the Low Kit, the Power Card and
the Brake.
Removing the flywheel.
6. Unscrew the M20 ring anchoring the flywheel to the secondary
shaft.
7. Remove the flywheel.
