Page 6.19
6.10. THERE IS NO RESISTANCE
The equipment does not produce resistance if:
1. the Brake Board does not receive a speed signal: if the equipment is stationary, then this
behaviour is correct. If, on the other hand, the equipment is in movement, then there might be a
problem with the reading of the RPM by the speed sensor, if it is mains-powered equipment.
2. the Brake Board does not generate any current: if the equipment is stationary, then this
behaviour is correct. If, on the other hand, the equipment is in movement, then there might be a
problem with the reading of the RPM by the speed sensor, if it is mains-powered equipment.
3. the Brake Board was not programmed correctly with the sequence of Firmware (FW), Brake
Table and Standard Settings;
4. the Electromagnetic Brake is faulty;
5. the Speed Sensor does not read the RPM correctly: it is faulty or incorrectly assembled (this is
only valid for mains-powered boards);
Continues on the next page...
