7.13. DISASSEMBLY OF THE REAR GUARDS
OPERATION
DESCRIPTION
Disassembly of the rear
guards
1. Disconnect the platform lever from the crank (see “Platform
Lever” dismantling procedure.
2. Remove the crank guard cover.
3. Unscrew the 2 screws anchoring the round "mirror-finish" guard
to the frame, using a 4 mm hex key.
4. Remove the lower central tunnel (assembly wi
th Fast Milano
fastener).
5.
Remove the central (front) guard covering the mechanics. 1
screw, using a 4 mm hex key + Fast Milano fastener.
6.
Remove the central (rear) guard covering the mechanics
(assembly with Fast Milano fastener).
On the right-hand side of the equipment.
7.
Unscrew the screw anchoring the side guard covering the
mechanics to the central tunnel frame, using a 4 mm hex key.
8.
Unscrew the 11 screws anchoring the side guard covering the
assembly to the frame, using a 4 mm hex key and remove it.
On the left-hand side of the equipment.
9.
Unscrew the screw anchoring the side guard covering the
mechanics to the central tunnel frame, using a 4 mm hex key.
10.
Unscrew the 10 screws anchoring the side guard covering the
assembly to the frame, using a 4 mm hex key and remove it.
