CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 7.1
7. PART DISASSEMBLY
7.1. DISASSEMBLY OF THE REAR DISPLAY COVER
OPERATION
DESCRIPTION
Disassembly of the
rear display cover
1. Switch off the equipment and disconnect the power supply plug from
the wall socket.
2. Remove the CSafe and USB connectors from the rear of the display.
3. Remove the screw under the cover that you have removed, using a Phillips
screwdriver.
4. Remove the rear display cover (assembly with Fast Milano fastener).
