Technogym CROSS PERSONAL - Dismantling the Crank Assembly Belt

CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 7.12
7.12. DISMANTLING THE CRANK ASSEMBLY BELT
OPERATION
DESCRIPTION
Dismantling the Crank
assembly belt
1. Dismantle the “Mechanics/crank assembly”.
2. Slacken the belt tension by turning the belt
stretcher eccentric
anchor screw, using a 5 mm hex key.
3. Remove the belt.
NOTE: during reassembly, perform the “Mechanics/Crank
assembling shaping procedure”.
