7.7. DISMANTLING THE AMPLIFIER/SPEAKERS
OPERATION
DESCRIPTION
Dismantling the
Amplifier/speakers
1. Remove the “Front guards”.
2. Remove the guards covering the
speakers on the column. 2
screws, using a 3 mm hex key.
3. Remove the speakers. 2 screws each, using a 3 mm hex key.
4. Remove the amplifier. 2 screws, using a Phillips screwdriver.
