Technogym CROSS PERSONAL - Dismantling the Display Boards

CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 7.4
7.4. DISMANTLING THE DISPLAY BOARDS
OPERATION
DESCRIPTION
Dismantling the Display
Boards
1. Switch off the equipment and disconnect the power supply
plug from the wall socket.
2. Remover the “Rear display cover”.
3.
Disconnect the following cables from the CPU: iPod
docking station and AUX inputs.
4.
Remove the plastic grille protecting the display boards. 8
screws, using a Phillips screwdriver.
NOTE: Be careful
with the WiFi card aerial cables
attached to the plastic grille, disconnect them from
the WiFi card.
5. You can now remove:
• LCD Inverter;
• WiFi card;
• Tuner card.
